Polar Power DC Diesel Generators for Hybrid Electric Marine Propulsion, Off Grid Energy, Solar Power and 12 Volt to 300 Volt Micro Grid Systems for Industrial Oilfield & Pipeline projects, Recreational Property, Cabins & more.

Get Lithium.com offers all the Lithionics Battery deep cycle, house power and engine starting lithium-ion batteries for recreational vehicles, sailboats, yachts, buses and campers, Marine, backup or emergency power, solar power generation plus Elco Electric Boat Motors, solar power products, Polar Power DC generators, high power inverter-chargers and alternators and more

High Performance, American Made, Powerful, Polar Power Diesel Generators For Mobile Marine and Micro-Grid Applications For Use With
Lithionics Battery Lithium-Ion Batteries

ULTRA EFFICIENT POLAR POWER DC MARINE GENERATOS/ OFF-GRID DC GENERATORS AND DC BACKUP GENERATORS

Pinnacle Innovations, getlithium.com and Polar Power are committed to winning your Hybrid Electric Energy Project business!

Be sure to ask us about the benefits of DC Alternator Charging via the American Made Polar Power DC Diesel Generators! We now offer the full line of Polar Power DC generators (shown below) and we can provide you with all the components needed to reap the huge benefits of DC Alternators. The main advantage is far faster / far higher charging efficiency which translates to huge increases in lithium battery charging efficiency. Fuel savings are another added benefit of the Polar DC direct generators. We can set you up with the DC Alternators and DC direct Inverter Converters. Send us an email to learn more: siteinfo@shaw.ca

Why choose Polar Power DC Diesel Generators?
Efficiency, durability and superb engineering/ manufacturing is the answer.

A few good reasons to go with a Polar DC Generator for Electric Marine Propulsion/ Off-Grid/ Grid-tie Clean Energy Projects:

Fuel savings up to 70% are realized when a Polar DC generator 10 kW -15 kW replaces a 20 kVA - 40 kVA AC generator.
Basically, a 10kw DC replaces a 15-25kw AC generator.
A 15kw DC can replace a 30-50kw AC generator.
Larger AC generators are used in applications powering smaller loads because the larger AC generators are built more robust than smaller standby AC generators.
AC generators need to be over-sized to handle surge/start up currents from the load.
Polar DC Generators do not need to be oversized as the outputs are both current and voltage regulated.
Polar's small DC Generators are built to handle both Backup and Prime power applications.
There is no need for excess battery strings on site, or an ATS. This keeps install costs down, as well as battery replacement costs from both the starter battery side as well as the onsite reserve batteries.
Reducing the onsite battery strings, also allows you to reduce the number of rectifiers required, an additional cost savings.
No lead acid starter battery, thus no replacement costs for. We use a small supercapacitor that is designed for 15-20 years.
Smaller footprint and lighter weight is ideal for Rooftop Applications. In most cases can be delivered to the roof via the service elevator, in return saving on installation costs.

For Backup Power/ Off-grid Power Diesel and Propane/ Natural Gas Generators check down the page...

Click here to view the AC generator versus Polar Power DC generator comparison PDF document

New for 2024:
Polar Power DC diesel generator with
15kW (slow speed) to
20kW (high speed) output

Our Client in Florida is installing two of these DC marine generators on their 51' Catamaran and each generator/ battery bank will be powering one Electric Yacht 51 Volt DC / 50kW electric marine motor on each side.

New for 2024 - Polar Power 8340VP-30 15kW DC diesel marine generator - click for a larger image...

Polar Power DC diesel generator with
3kW to 5kW output

Polar Power DC diesel generator with
13kW to 20kW output

Polar Power DC diesel generator with
4kW to 8kW output

Polar Power DC diesel generator with
9kW to 14kW output

26kW Polar Power Generator - Click here for the details page...

Click here for the Polar Power Supra Control System Brochure...

Click here for the Polar Power Supra Control System Manual

Polar Power DC Generators are fully automated fuel powered battery chargers.
The Generator is supplied complete with the necessary microprocessor-based controls and software allowing the Generator to sense the battery state of charge and automatically start and stop.
NOTE: The maximum Amp output of the Polar Power DC Marine Generators is 360 Amps.

What's New?
Polar Power is in the process of updating the base engines used in their Marine DC Diesel Generators. Presently, we can offer the 9 to 14kW 8340VP-30 model as well as either the 15kW (low speed) or 20kW (high speed) 8340VP-30 model - with additional models to be ready soon. In addition, Polar Power has somewhat changed the process of selling and commissioning the marine generators. In the past, we were able to purchase, ship and do the on-site generator commissioning and warranty validation process through extensive on-site testing and reporting of data through Polar's GUI software.

Polar has found that with many inexperienced technicians this was a problematic process so now Polar needs to send one of their engineers to your project site to perform the commissioning and warranty validation process once installation is completed. For most projects in Canada and the lower 48 USA States Polar charges approximately $4,000.00 USD in addition to the price of the generator for this service. This cost includes the engineer's travel and accomodations as well as the commissioning procedure. Pinnacle Innovations can often negotiate a package price with some discounts if your project requires more than Polar generator - see below.

Pinnacle Innovations/ getlithium.com Polar Power DC Generator Consultation Service:
We will be happy to help you evaluate, purchase and implement an efficient, durable and much quieter American Made Polar Power Marine DC Generator for your project. Here, we offer you the Polar Generator at the same cost as we can buy at plus we add a flat $2,000.00 USD fee and this covers up to 15 hours on the project that covers things like the following:

the preliminary information gathering/ sharing as to your project needs
completing and submitting Polar's technical project specification worksheet
identifying which generator options that you will need (such as communications, starting method, use of a secondary belt-driven alternator etc.)
identifying what spare parts that you may want to order with the generator and to have on hand for frequently consumed items/ high wear items that can include spare oil changes/ filters, spare belts, spare starting system and so on
arranging Customs Broker Services if you do not have that and you are not located in the USA
assisting you with determining of you need any DC power converters to provide battery charging to lower Voltage (or higher Voltage) battery banks
helping you evaluate what type/ chemistry of battery system will serve you best
negotiating the best price for all that you need - including the Polar Power engineer's visit to your project for generator commissioning/ warranty approval
arranging with Polar a deposit for the order, with the balance due 2 weeks prior to the expected shipping date.

If purchasing 2 or more generators at the same time, Pinnacle's fee will be reduced to $1,500.00 USD per generator.

POLAR POWER DC MARINE GENERATORS - CONFIGURABLE FROM 12 VOLTS TO 550 VOLTS DC - PRICES AND MODELS SUBJECT TO CHANGE*
PART NUMBER	DESCRIPTION	PRICE USD*	KW RANGE
8080VP-13	VOLVO PENTA D1-13 ENGINE - 8080 ALTERNATOR	$16,295.00*	3 - 5 kW
8080VP-20	VOLVO PENTA D1-20 ENGINE - 8080 ALTERNATOR	$17,595.00*	4 - 8 kW
8220VP-20	VOLVO PENTA D1-20 ENGINE - 8220 ALTERNATOR	$18,575.00*	5 - 9 kW
8220VP-30	VOLVO PENTA D1-30 ENGINE - 8220 ALTERNATOR	$20,175.00*	9 - 14 kW
8220VP-40	VOLVO PENTA D2-40 ENGINE - 8220 ALTERNATOR	$20,910.00*	13 - 18 kW
8340VP-30 New for 2024!	YANMAR MARINE DIESEL ENGINE - 8220 ALTERNATOR OR 8340 ALTERNATOR See pictures above	$22,630.00*	9 - 20 kW
8340VP-40	VOLVO PENTA D2-40 ENGINE - 8340 ALTERNATOR	$24,565.00*	13 - 20 kW
8340P-40422	PERKINS 404D-22 ENGINE - 8340 ALTERNATOR *Details link...* (not suitable for marine)	Call*	18 - 26 kW
8340VP-55	VOLVO PENTA D2-55 ENGINE - 8340 ALTERNATOR Great for electric marine propulsion.	$28,969.00*	16 - 26 kW
3TNV88-DBSA	Yanmar Marine 3TNV88 or Yanmar Industrial 3TNV88 diesel engine (marinized by Polar) coupled to the Polar Power 8340 alternator. A great solution for 48 Volt to 160 Volt hybrid-electric marine propulsion projects. *NOTE: The Yanmar Industrial* 3TNV88 diesel engine is the lower cost, more efficient and quieter option.**	Call*	20 kW Yanmar Industrial 3TNV88 Diesel Engine PDF:
ACCESSORIES:
88-25-0500	SOFT ENCLOSURE. Reduces noise levels but complicates maintenance.	From $1,990.00*
00-10-0008	DC TO DC CONVERTER	$250.00*
20-27-0002	ELECTRIC FUEL PUMP	$165.00*
84-28-0002	24 VOLT to 12 VOLT SUPER CAPACITOR STARTING KIT	$1,080.00*
84-28-0001	48 VOLT to 12 VOLT SUPER CAPACITOR STARTING KIT	$950.00*
08-13-0039	BATTERY AND LOAD MONITORING ASSEMBLY	$225.00 TO $355.00*
24 Volt Kit	24 VOLT GENERATOR STARTER AND SMALL ALTERNATOR CONVERSION KIT. INCLUDES STARTER, BALMAR ALTERNATOR AND EXTERNAL VOLTAGE REGULATOR, GLOW PLUGS, DIFFERENT BELT AND PULLEYS AND SOME ADDITIONAL MOUNTING COMPONENTS. Recommended for use when no 12 Volt battery system is present on the project but there are one or more 24 Volt battery banks in place.	$2,795.00*
OPTIONS:
Remote Communication Options:
1.	RS232
2.	CAN bus
3.	SNMP
4.	Ethernet
Automatic Control Options:
1.	Battery monitoring and temperature compensation
2.	Fuel level monitoring
3.	Remote operator panel
Grounding:
1.	Tie negative ground to engine
2.	Isolated engine ground system
Will you be using engine waste heat for:
1.	Potable water
2.	Space heating
3.	No waste heat recovery
Additional Information to Provide us Information On:
Timescale when generators are needed: Number of generators to be installed on vessel: Ambient temperature range: Unusual generator conditions include: Desired run hours between service calls: Total number of run hours per year: Vessel length and: Multi-hull, Mono-hull, Sailing, Power Generator Specs: DC Voltage Range (required) Output Curent Load Current Total energy consumption kWh/ day: (required) Desired Decibel Noise Level:
Notes: Polar Power DC generators typically come equipped with the following equipment: Marinized Engine (water/glycol in the engine block coupled with a Cupro-Nickel seawater heat exchanger), 8000 Series Alternator, 12 Volt DC engine starter with a secondary 12 Volt output Alternator (smaller than the main generator Alternator) for recharging the starting battery and other 12 Volt batteries (we can also provide a 24 Volt starter and secondary 24 Volt Alternator at additional cost), Wiring harness, Supra Automatic Charging Control System. Note: Polar Generators and the Supra Control System are CANbus controlled and generally third party devices are not allowed to control generation operation. When the generator is used with lithium-ion batteries equipped with a BMS that has a Generator Auto-Start Function, you can use the the Polar e-stop for emergency shut-off from the BMS signal, or you can disconnect power to the Polar generator electronic fuel pump, or you can control the generator through CAN protocol from the BMS. If none of these options are possible, we would set the generator to Auto mode, but the main thing to keep in mind is that you cannot let the BMS disconnect the battery while the generator is running. Remote Display and Control for the Operator Air Filter Captive Vibration Mounts and Mounting Frame Polar offers their DC generators with 2 "Speed" options that relate to the kW ratings above: "Slow Speed" - this means the generator is set to run in the 1,600 to 1,900 RPM range. Customers choose this option when they want bigger fuel savings, less noise and almost double the life expectancy of the generator. The Slow Speed option also means less frequent oil and filter changes. "High Speed" - this means the generator is set to run in the 2,500 to 3,000 RPM range. Customers choose this option when they need more power and/ or faster battery bank charging. If the alternator winding permits it, Polar can program the DC generator to run in the 1,900 to 2,400 RPM range that bridges the gap between the kW output of the Slow Speed versus High Speed option. Although the Polar Power DC Generators can be configured to a wide variety of Voltages, the main big alternator is typically limited to to 375 Amps of DC current output or less. For projects requiring more than 375 Amps we often need to couple two generators in the system. *We offer a 2.25% discount for payment by cheque, Interac or Bank Transfer. All prices are subject to change without notice.

Polar Power 24 Volt diesel generator installed

Polar Power DC diesel generators can output from 12 Volts to 550 Volts DC. To accomplish this Polar has a variety of alternator windings and models to choose from. This also gives Polar generators the ability to offer specific Voltage ranges at different engine speeds. The higher the Volatge that you decide on the greater will be your choice for engine speeds. Higher Voltages are beneficial to reduce the need for higher currents.

For more information on Polar Power DC Generators or to order,
just give us a Call at 604-510-0800 or Email Us at: siteinfo@shaw.ca

POLAR POWER OFF-GRID/ BACKUP GENERATORS

We also offer a DC generators by Polar Power for Off-grid/ Grid-tie, Backup Power and Industrial Applications. These are in use with great success in areas such as Alaska/ Northern Canada and can be operated in extreme temperature climates. Below are just a few of the generators available.

Generator Model

Graphic

Polar Power 6 to 15kW DC Diesel Powered Generators

Founded in 1979 Polar Power specialized in solar photovoltaic systems, solar air conditioning and refrigeration. We developed and provided photovoltaic charging controls for telecommunications in the 1980s along with DC generators for the military. In 1994 we were first to provide DC generators with remote control and monitoring to the telecommunications industry.

Polar's success is based on engineering generators to meet the very specific needs of each application. Telecom site optimization is best met with the DC generator technology as the loads and batteries are DC. It makes no sense to install an AC generator and convert the output to DC. The AC generators are designed for a wide range of applications and they are not specifically produced for telecom applications so there are issues with reliability, space, and fuel efficiency. Polar can save you considerable time and cost in permitting, installing, purchasing, and maintaining a backup generator. We reduce CAPEX and OPEX costs while improving backup reliability.

FEATURES:
SMALL FOOTPRINT. Polar's DC generator is considerably smaller in size than an AC generator. You can now backup sites that could not accommodate an AC generator. Smaller also means less cost for space leasing.

LOW MAINTENANCE. Due to oversized oil sump, and oil/fuel filtration system.

LOW ACOUSTIC NOISE. <62 dBA at 7 meters for diesel, and low vibration so as not to disturb the local residents or building landlords.

LIGHTWEIGHT. Up to 1/3 the weight of a comparable AC generator.

CORROSION RESISTANT. All-aluminum enclosure with stainless hardware for low maintenance, and long service life.

FUEL EFFICIENT. Up to 85% fuel savings due to smaller engine displacement, high efficiency alternator, and variable speed operation.

RODENT RESISTANT. Small animals can quickly destroy a generator set by gnawing on wires, fuel lines, radiator hoses, etc. Cooling air inlets and outlets have perforated aluminum screens to keep small rodents and large insects out. Stainless steel wire braid is placed over fuel and radiator lines to prevent damage.

SUPERCAPACITOR STARTER. Failure to start is the number one problem plaguing generator reliability and typically this is caused by a bad starting battery. Polar unique design has replaced the starting battery with a Super Capacitor. Capacitors are more reliable and last longer than batteries (10-15 year life).

LONG LIFE. Controls and wire harnesses are designed to exceed a 20 year life. Higher grade, longer life electrical wire (UL 3173), weather tight connectors, gold plated connector pins on signal circuits. No transfer switches are required.

ADVANCED MONITORING. Remote diagnostics, control, and monitoring. Ethernet and RS232 standard, with optional SNMP.

Polar Diesel Generator Data Sheet

Click on the image for larger graphic:

Click here to view the AC generator versus Polar Power DC generator
comparison PDF document

Polar Power 10 to 15kW DC Propane/ Natural Gas Powered Generators

LOW MAINTENANCE. Due to oversized oil sump, and oil/fuel filtration system.

LOW ACOUSTIC NOISE. <62 dBA at 7 meters for diesel, and low vibration so as not to disturb the local residents or building landlords.

LIGHTWEIGHT. Up to 1/3 the weight of a comparable AC generator.

CORROSION RESISTANT. All-aluminum enclosure with stainless hardware for low maintenance, and long service life.

FUEL EFFICIENT. Up to 85% fuel savings due to smaller engine displacement, high efficiency alternator, and variable speed operation.

ADVANCED MONITORING. Remote diagnostics, control, and monitoring. Ethernet and RS232 standard, with optional SNMP.

Polar Propane/ Natural Gas Generator
Data Sheet

Click on the images for a larger graphic:

Polar Power Natural Gas powered 10kW DC generator model 9220K-972

UL approved Lithionics lithium-ion 48 Volt battery with 150 Amp hours capacity. For use with external BMS. Details page...	Deep cycle lithium ion batteries for Camping Trailers, Class A, B and C Motorhome RV's
Deep cycle/ engine cranking lithium ion batteries for Power Boats & Yachts	Lithionics lithium-ion 12 Volt battery with 600 Amp hours capacity. For use with external BMS. Details page...

Be sure to check our "Overview of our Lithium ion Batteries" page.

There you can find out about all the advantages of using our Lithium ion Batteries from Lithionics Battery, as well as determine what battery will replace your existing lead-acid battery.
