GTX
Series Lithium Ion Battery and Accessories
All Prices $USD. Contact Us for Shipping/ Freight Costs.
|
|
|
|
|
|
|
Battery
Model
|
Applications
|
Volts
|
Watt
Hours
|
RC
Mins
|
Ahr
|
Weight
|
Dimensions
|
Price*
|
|
GTX
12V 630A
E2112-CS200
Lithionics
Battery 12 Volt Lithium-ion Battery
UN DOT 38.3 & other ratings
|
Mercedes/
Dodge Sprinter Vans, RV, Light
Trucks, Solar power, Industrial applications
|
12.8
|
8,064
|
|
630
|
Approx.
128 Lbs
|
20.3"
x 12.3" x 10.6" overall height.
|
From
$8,838.64 USD
|
|
|
|
NEW
- High Power, Compact, Internal BMS, Low Price, Internal
Automated Heater and Bluetooth SOC Included!
Many Mercedes/ Dodge Sprinter Van owners choose this 630
Amp hour lithium-ion battery for their van conversions,
RV's, yachts or other applications. Please inform us
of the intended orientation of the battery before ordering.
A
great, lightweight lithium ion battery with 630 Lithium
Amp Hours Reserve Capacity and 8,064 Total Watt Hours capacity.
Now with ANSI/CAN/UL -1973:2018 approval. This is
one of the most compact, high performance and well priced
Lithionics lithium-ion batteries that we offer.
IMPORTANT
NOTES:
-
- Although
it is recommended to use two of these batteries in parallel
to run a 3,000 Watt inverter-charger, if using one of
these batteries connected to a 3,000 Watt inverter-charger
(such as Victron Multiplus, Xantrex Freedom PRO XC,
Kisae 3kW) it is required to use at least 2 feet of
2/0 DC power cabling between the inverter-charger and
the bus barsas well as at least 2 feet of 2/0 DC power
cabling between the battery system and the bus bars.
Please do not use the bigger 4/0 DC power cable. The
smaller power cable helps to dampen the big inverter-charger's
"in-rush currents" and will help eliminate
inverter startup errors that can happen in rare instances.
In addition, you will need to install a mechanical battery
disconnect switch rated at 350 constant Amps or higher
between the battery and the bus bar as well as between
the bus bar and the inverter-charger.
- When
using one or two of these batteries AND a 3,000 Watt
or 3,000 kVA inverter-charger it is required to have
two 400 Amp or higher rated manual battery/ inverter
disconnect switches. One installs between the battery(s)
and the positive bus bar and one installs between the
positive bus bar and the inverter. In addition, we require
either an MRBF terminal block fuse or Class T fuse connected
to/ from the positive battery terminal(s) to the positive
bus bar and either a Class T or MEGA Fuse must be installed
between the positive bus bar and the inverter. Pinnacle
Innovations/ getlithium.com can supply our valued Clients
with all of these installation components at minimal
additional cost.
- In
addition, please follow these operational instructions
when using one or two of these batteries with either
a 2,000 or 3,000 Watt inverter-charger:
- Shut-Down:
- First,
turn off major 120 VAC inverter loads.
- Next,
turn off the inverter-charger.
- Next,
turn off the inverter disconnect switch.
- Next,
turn off the battery disconnect switch.
- Finally,
turn the battery(s) off.
- Start-Up:
- Make
sure that major 120VAC inverter loads are switched
off.
- First,
turn the battery(s) on.
- Next,
turn the master battery disconnect switch on.
- Next,
turn the inverter disconnect switch on.
- Finally,
turn on the inverter.
- NO
MARINE USE: Unfortunately
we can no longer warranty approve the use of internal
BMS Lithionics batteries like this model as well as
the 130 Amp hour and 630 Amp hour internal BMS Lithionics
batteries for Marine Applications. For Marine Applications
we always need to use battery modules with the more
robust external NeverDie Battery Management System (BMS).
- We
will be posting new and warranty approved Lithionics
installation wiring diagrams shortly.
|
Click
on the PDF logo to the right for the Lithionics Battery
spec sheet in PDF format.
The Lithionics Batteries are "lithium-ion"
which is the short term for lithium iron phosphate
and the chemistry name for the batteries is the super
safe and reliable "LiFePO4".
|
|
|
Click
on the PDF logo to the right to view the Lithionics
Battery "EURO DIN Connector Bulletin" that
shows what to watch for when plugging the EURO DIN
Connector Harnesses in between the Lithionics Lithium-ion
Batteries/ NeverDie Battery Management System/ Combiner
Boxes
|
|
|
Click on the PDF logo to the right to view the Lithionics
Battery Battery Charger Approved Settings Guide
|
|
|
Click on the PDF logo to the right to view the Lithionics
Battery Installation Guide
|
|
This
extremely versatile battery can be used for a wide variety
of applications including Deep Cycle House Power for RV
and Marine applications as well as a diesel engine cranking
battery for Truck Engines and for Marine Engine Starting
on sailboats and yachts.
This
battery is a dual-use battery: Deep Cycle Battery House
Power or as a Primary Engine Starting Battery or Main Vehicle
Battery. Lithionics lithium-ion batteries are the ideal
solution for Solar Power Harvesting and Off-Grid Electrical
Energy Storage as they harvest more energy than lead type
batteries.
ADDITIONAL
NOTES:
1. Heater Function:
When the battery is turned Off (for Winter storage etc.)
this also turns off the battery's internal heater system
so that the battery does not deplete when stored in cold
temperatures. Refer
to the Lithionics Storage Procedures PDF for storage instructions.
2. Alternator Charging:
The long-term effects of constant charging from "unregulated/
controlled alternators" are indicating possible degradation
of lithium-ion batteries. As such, we only recommend directly
connecting a Lithionics battery system to a high quality
alternator that connects to either a Wakespeed or Balmar
branded external Voltage Regulator that can offer proper
3 stage charging AND the Lithionics BMS option "FCC"
can turn off the alternator when the lithium battery is
full. For alternators that are "shared" and need
to charge a lead-acid/ AGM start battery as well as the
Lithionics battery we recommend using a high quality DC
to DC Battery Charger like those made by Sterling Power
(ignition enabled option) that will connect to your start
battery and feed the Lithionics Battery. Please consult
Pinnacle Innovations and we will be happy to specify how
best to achieve alternator charging and we can also supply
any parts needed - such as DC to DC Battery Chargers, Wakespeed
or Balmar branded external Voltage Regulators and high efficiency
battery isolators by Perfect
Switch. Contact Us
Page...
3. Although this battery can power a 3,000 Watt inverter-charger
it is really pushing the limit of the 200 constant Amp rated
internal BMS (can handle 250 Amps for short periods) as
at 3,000 Watts output the inverter can draw almost 240 Amps.
As such, we either recommend using two of the GTX 630 Amp
hour batteries, you choose the GTX 630 Amp hour battery
module that can use a 350 Amp to 400 Amp external BMS
box or that you program the inverter's output downwards
to say 2,500 Watts.
4. We also offer an illuminated remote on/off/reset
switch that lets you control the battery from a convenient
location. It comes with 15 feet of wire - we can make that
length longer for a small additional fee. It sells for $134.64
USD.
OPTIONS:
This battery is available with convenient carry handles
for an additional $134.64 USD.
We also offer a "Cold Weather Protection System"
for this battery:
Lithionics
Internal Lithium-ion Battery Heater Kits Type 1 and
Type 2 for Version 8 external BMS |
Theory
of Operation:
The heater kit is a convecting type heating system
internal the battery or module that applies and
average of 30 Watts per hour (at -4F/-20C continuous
ambient temperatures) and is controlled by a thermostat.
The thermostat maintains the lithium cell/core to
a temperature between 35 and 40 degrees fahrenheit.
This permits sub-freezing charging operations.
|
NOTE:
NOT AVAILABLE FOR STANDARD SERIES BATTERIES.
|
|
EXTREME CONDITIONS: We also sell a product called
"Dynaliner" that is an
external thermal protective wrap with a K Value of .3.
This "Dynaliner" material is .5"
thick and non-conductive.
This option is recommended for extreme temperature situations
for $295.50.
PRICING:
2.25% Discount For Wire Transfer, Cheque, Debit or Cash
Payments.
Fleet Pricing, and Volume Discounts also
available.
Prices may be lower for in-stock items or for multiple items
ordered
in a single shipment.
* All Prices Subject to Change. Shipping/ Freight is extra.
Notes:
1 Lithium Amp Hour = 2 Lead Acid Amp Hours in 12 Volt applications,
2.5 Ahr in 24 Volt applications and 3.5 Ahr in 48 Volt applications.
Lithionics Battery Charging Parameters:
For Lithionics 12 Volt lithium-ion
battery systems:
Charge
14.4 Volts. Float 13.4 to 13.6 Volts.
High
Voltage Cutoff (HVC) 15.6 Volts.
For Lithionics 24 Volt lithium-ion
battery systems:
Charge
28.8 Volts. Float 26.8 to 29.2 Volts.
High
Voltage Cutoff (HVC) 31.2 Volts.
For Lithionics 36 Volt lithium-ion
battery systems:
Charge
43.2 Volts. Float 40.2 Volts to 40.8 Volts.
High
Voltage Cutoff (HVC) 46.8 Volts.
For Lithionics 48 Volt lithium-ion
battery systems:
Charge
54.75 Volts. Float 50.25 Volts.
For Lithionics 51 Volt lithium-ion
battery systems:
Charge
58.4 Volts. Float 53.6 Volts.
For modern, programmable 3rd party
inverter/chargers etc.,
we
recommend using "Custom
Settings" - if there is no prevision
you
can try the "GEL" battery setting..
If
in doubt, please Contact
Us.
Lithionics Battery recommends Customers to purchase
one of our low-cost "KF series" smart lithium-ion
battery chargers when you purchase one of our smaller "Engine
Starting" lithium-ion batteries.
Click
here
for details on the KF series Battery Chargers...
- Lithionics
Battery Lithium Ion Battery Life:
- 5,800
cycles at 50% Depth of Discharge
- 3,000
cycles at 80% Depth of Discharge
- 2,200
cycles at 90% Depth of Discharge
Note: At the end of the cycles the battery will
still work fine and can last many more years but
may have lost up to 20% of the original Amp hour
capacity.
- Our
batteries typically have a 10 Year+ Service Life
- Warranty
Page...
- Lithium
Ion Battery Industry SAFETY LEADER: Approved to U.N.
International D.O.T. 38.3 for Lithium - many BMS and
battery models also UL approved.
- NEVERDIE
SYSTEM NOTES AND FREQUENCY OF CHARGING:
A.) The "Pushbutton NeverDie System" has a
continuous Amperage draw of 2 Milliamps.
B.) Some of our Lithionics Battery lithium-ion batteries
can be ordered with either "Pushbutton NeverDie
System" (A) which is the BMS built into the battery
or can be ordered with the "External BMS box Pushbutton
NeverDie System" (B). As such, our smaller batteries
will likely need some recharging every 2-4 months to
compensate for the small amperage draw (.002 Amp) of
the NeverDie System. Please be sure to ask about this
at time of ordering or check the Lithionics Storage
Procedure Guidelines.
If your application also has a small "Parasitic
Drain" (clock, alarm system etc.), this must also
be factored in and the battery charged in accordance
with the total amperage draw.
Lithionics Battery lithium-ion batteries are 98% EFFICIENT
FOR SOLAR POWER. Compare that with only 55% to 85% efficiency
for other types of batteries including deep-cycle lead acid
batteries. Lithionics Battery lithium-ion batteries also
charge from 2 to 10+ times faster than other batteries, which gives
you more use out of your lithium-ion battery. Visit our
Solar
Power page...
We also
offer a great selection of solar panels suitable for RV's,
yachts and sailboats of all sizes - including durable flexible
solar panels that can be walked on.
Battery
Meters/ State-of-Charge
Meters and Gauges are also available at additional cost.
For multiple battery systems, our Neverdie Control Box may
also be required.
|
|
|
|
|
|
|
|
|
|
|
|
|
Finally,
there is a powerful, reliable alternative
to Torqeedo Electric Outboards - the new series
of Elco Electric
Outboard Motors!
|
|
Pinnacle
Innovations is a Systems Integration Company offering
Lithionics Battery lithium-ion batteries, advanced electrical
components/ solar systems for RV/ Marine/ Off-grid and
Elco electric/ hybrid-electric marine propulsion systems
for sale in the USA, Internationally and all across
Canada including the following cities (and other Canadian
cities): Toronto, Montreal, Calgary, Ottawa, Edmonton,
Mississauga, Winnipeg, Vancouver, Brampton, Hamilton,
Quebec City, Surrey, Langley, Laval, Halifax, London,
Markham, Vaughan, Gatineau, Longeil, Burnaby, Saskatoon,
Kitchener, Windsor, Regina, Richmond, Richmond Hill,
Oakville, Abbotsford, Chiliwack, Burlington, Sudbury,
Sherbrooke, Oshawa, Barrie, Kingston, Cambridge, Coquitlam,
Langley, Whitby, Guelph, Kelowna, Saanich, Victoria,
Nanaimo, Thunder Bay, St. John's, Red Deer, Kamloops,
Fort MacMurray, Fredericton, Grande Prairie, North Bay,
Whistler, Prince George, Pickering, North Vancouver,
Aurora, Shawinigan, Moncton, Saint John, Lethbridge
& more. International Orders are also possible
and are Sales Tax Exempt.
|
|
|
|
|
Need
Accessories for Your Lithionics Lithium Ion Battery?
We got you covered...
|
|
|
-
High and Low Frequency
- External & Installed Chargers
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ADDITIONAL NOTES:
** Working Life with batteries equipped with the NeverDie
System that helps prevents
over-discharging. Refer
to the Lithionics Cycle Life Chart for more details.
"CA" means Continuous Cranking Amps
"CCA" means Cold Cranking Amps
"Ahr" means Amp Hours.
Note: 1 Lithium Ion AHr = 2 Lead Acid AHr in
12 Volt Applications - the advantage is higher in
higher Voltage Lithionics lithium-ion battery applications.
"EXT" means Extended Height battery
"RH" means Reduced Height battery
Please check our battery sizes to ensure correct
fit Before Ordering
NEVERDIE system included
where shown.
NEVERDIE system option
available at extra cost: Click
here to visit the NeverDie
Battery Management Systems page for full details and
pricing
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
You
may ask "What is NEVERDIE?"
NeverDie is
an option that can be ordered with ALL of our batteries at
extra cost. This is a Low Voltage Cutoff (LVC) circuitry built
into the battery that will allow you to use the electricity
in your deep cycle lithium-ion battery with the engine off
and the battery will automatically enter "sleep mode"
once the battery is drawn down to typically 90% discharged.
This means you can use approximately 90% of the energy in
the battery before it enters "sleep mode". This
helps to prevent accidental overdischarging.
If
you order the NEVERDIE Pushbutton, a simple
button will be located on the top of your battery to manually
shut down the battery for storage or to "wake up"
the battery from sleep mode.
|
|
|
|
|
| |
|
|
|
|
|
MORE POWER
|
1/5 WEIGHT OF LEAD-ACID
|
20 YEAR SERVICE LIFE
|
ENVIRONMENTALLY FRIENDLY
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
~ Deep Cycle Lithium
~ Engine Cranking Lithium
~ RV Lithium Batteries
~ Marine Lithium Batteries
~ Large Scale Batteries
~ Solar Power Batteries
~ Truck Industry Batteries
|
~ Lithionics Battery
NeverDie
BMS
~ Dual Channel BMS
~ State of Charge
Monitoring
Systems (SOC)
~ CANbus Controls
~ Alternator Controls |
~ Sailboat/
Yacht Inboard &
Outboard Electric motors
~ 5hp, 9.9hp, 14hp, 20hp, 30hp & 50hp
electric outboards
~ 6hp, 12hp, 20hp, 40hp, 70hp and
100hp electric inboards
~ BestGo Lithium-ion and
Victron Energy AGM Batteries |
~ Sailboats
~ Ski Boats
~ Bass Boats
~ Sport Cruisers
~ Offshore Racing Boats
~ Yachts
~ High Output Alternators with
External
Wakespeed or
Balmar Voltage Regulators |
~
Class A, B & C Lithium-ion Batteries
~ Mercedes Benz Sprinter Van
Lithium-ion
Batteries
~ Deep Cycle & Engine Cranking
Lithium-ion
Battery Systems
~ High Output Alternators with External Wakespeed
or Balmar Voltage
Regulators
|
~
Email Us
~ Hours
~ Address
~ About Pinnacle
Innovations
|
|
Lithium-ion
batteries for sale across Canada in British Columbia (BC),
Alberta (AB), Saskatchewan (SK), Manitoba (MB), Ontario
(ON), Quebec (QC), New Brunswick (NB), Nova Scotia (NS),
Prince Edward Island (PEI), Newfoundland (NL), Yukon Territory
(YT), Northwest Territory (NT), Nunavit (NU), Iqaluit, USA.
USA & International Orders are also possible.
Copyright getlithium.com, Lithionics Battery and Respective
Copyright Holders 2021. All rights reserved.
|
|
 |
|
|
|
|
